i would like to know where all the fuel lines go from fuel pump to carburetor to petcock on a late model 2004 polaris sportsman 500 ho Should be petcock to pump, pump to carb, carb to engine.. and you have a vacuum line that makes the pump work ..usually from carb/intake to pump. This item: Polaris Hose, Fuel (8450117-250) $31.08: Polaris CLAMP, HOSE (7080003) $0.56: ... This part is number 4 on this diagram Quantity required per assembly: 1. 2003 Polaris 500 Magnum 4X4 HDS (A03CD50FB) FUEL TANK and CARBURETOR MOUNTING - A03CD50FB. This part is number ...
That will tell you if the pump is working. If it is, look under the carb at the float bowl. There should be a screw next to a nipple with the overflow hose attached. If you loosen the screw, fuel should run out of the small tube or nipple if the tube isn't there. If you have fuel, then chances are you have a plugged jet so the carb has to come ...
